A high-precision CNC sawing machine

Views: 56     Author: Site Editor     Publish Time: 2022-06-20      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

The high-speed CNC sawing machine is one of the GooDa Machinery milling machine series, involving the field of sawing machines, more specifically, a high-precision CNC sawing machine.


Sawing machines use circular saw blades, saw bands or saw blades as tools to saw metal round materials, square materials, pipe materials and profiles. , pipe and other profiles, the driving wheel and the driven wheel drive the saw blade to run, the cutting direction of the saw blade is controlled by the guide rail control frame, and the band saw blade is straightened and straightened by adjusting the rotation bearing. The piston rod supports the guide rail and the control frame falls into the sawing material. The band sawing machine is equipped with a manual or hydraulic cylinder clamping and locking mechanism, as well as a hydraulically operated valve switch.


However, when the existing CNC sawing machine is actually used, because the sawing limit of the material is not complete enough during sawing, a large error will occur when the material is fixed, which affects the processing accuracy.


In order to overcome the above-mentioned defects of the prior art, GooDa introduced a high-precision CNC sawing machine to solve the problems raised in the above-mentioned background technology.


A high-precision CNC sawing machine includes a gantry frame, a placement frame is fixedly installed on the inner side of the middle part of the gantry frame, a support frame is arranged on one side of the gantry frame, and a chute is opened inside the support frame, so that the sliders at both ends of the positioning plate are arranged. It can slide inside the chute. The CNC sawing machine controls the rotation of the motor according to the required sawing length, and uses the gear drive assembly to drive the threaded rod installed inside the chute to rotate, so as to use the threaded connection between the threaded rod and the slider to control The positioning plate moves relative to the gantry to achieve precise control of the plate sawing.


The technical effects and advantages of the high-precision CNC sawing machine: realize the precise control of the plate sawing, greatly improve the precision and stability of the sawing of the device, and enhance the practicability and convenience of the use of the device.


GooDa Machinery high-speed CNC Saw Machine saw-450nc:

Motor power 15kw (optional 18.5kw, 22kw), cutting efficiency: 200-400mm/min, machining accuracy: roughness≤Ra3.2um, machining stroke: 450mm, machining range: 10-80*30-450mm plate, φ10-80mm round bar, rail form: hard rail + linear rail, hydraulic pressing, equipped with Mitsubishi system, saw blade size: 360mm.

Advantages: integrated sawing and milling, high precision and high output, new algorithm, batch setting, automatic feeding, automatic counting, optional water cooling configuration round bar, special machine for sawing small pieces of plate material.


Dongguan GooDa Machinery Manufacturing Co., Ltd. was established in 2012. The company is committed to the innovative research and development of efficient and intelligent steel plate cutting and processing to meet customers' needs for metal sheet cutting and processing. It has won a number of national patents and is a powerful manufacturer. Specializing in the production of circular sawing machines , integrating R&D, sales and service, with more than ten years of innovative spirit, GooDa Machinery has many years of experience in producing sawing machines, stable performance, quality assurance, and sells well all over the world, providing customers with professional and high-quality services. At present, the company's main products include: CNC double-sided milling machine, CNC gantry milling machine, CNC machining center, CNC high-speed sawing machine, CNC gantry grinder, CNC surface milling machine, CNC three-axis linkage chamfering machine, 180-degree turning machine and other domestic high-end CNC machine tools.(Website: www.goodagroup.com,hotline: +86-769-8976-0601/+86-138-1097-3752, email:Sales@goodacnc.com / toby@goodacnc.com.)
