TH-600NCH
GOODA
Availability: | |
---|---|
Quantity: | |
GooDa Double-Spindle Machining Center TH-600NCH with moving columns is mainly used for efficient milling, drilling, and tapping of large flat plates, new energy, flanges, ring parts, and other workpieces.
It can achieve drilling through-holes and blind holes on single-material parts or composite materials. It can achieve large-scale production with automation and high precision.
This type of machine can be customized according to your actual needs.
Auxiliary DevicesRetractable workpiece clamping: during feeding, the device automatically retracts to facilitate feeding. After feeding is completed, it automatically extends to clamp the workpiece. A fully automatic mechanical hand are available to achieve efficient automated processing. | Precision Rotary TableThe machine adopts a Taiwan indexing plate with precise positioning and strong heavy cutting ability. |
SpindleHigh-rigidity, high-torque spindle with high accuracy and strong cutting ability, suitable for cutting with large cutter. |
1. Guideway
Z-axis uses high-rigidity hard guideway and X, Y-axis uses roller linear guideway, suitable for heavy-duty cutting. With only one setup, it can continuously complete various processes such as milling, drilling, tapping, and more.
2. Casting
The machine bed is cast from HT300, with high stability and not easily deformed. The large-span base effectively disperses gravity and processing forces. The machine structure is sturdy, with high bed rigidity and processing stability.
3. System
Equipped with original Mitsubishi system, which is powerful and has excellent data processing capability. The original high-power Mitsubishi main motor provides excellent stability, fast response, and high accuracy.
4. Dual Tool Magazine
The machine comes with a dual tool magazine structure with the high-speed ATC system. Multiple processes done within only one setup such as milling, drilling, tapping of large and medium-batch parts, greatly improves production efficiency.
GooDa Double-Spindle Machining Center TH-600NCH with moving columns is mainly used for efficient milling, drilling, and tapping of large flat plates, new energy, flanges, ring parts, and other workpieces.
It can achieve drilling through-holes and blind holes on single-material parts or composite materials. It can achieve large-scale production with automation and high precision.
This type of machine can be customized according to your actual needs.
Auxiliary DevicesRetractable workpiece clamping: during feeding, the device automatically retracts to facilitate feeding. After feeding is completed, it automatically extends to clamp the workpiece. A fully automatic mechanical hand are available to achieve efficient automated processing. | Precision Rotary TableThe machine adopts a Taiwan indexing plate with precise positioning and strong heavy cutting ability. |
SpindleHigh-rigidity, high-torque spindle with high accuracy and strong cutting ability, suitable for cutting with large cutter. |
1. Guideway
Z-axis uses high-rigidity hard guideway and X, Y-axis uses roller linear guideway, suitable for heavy-duty cutting. With only one setup, it can continuously complete various processes such as milling, drilling, tapping, and more.
2. Casting
The machine bed is cast from HT300, with high stability and not easily deformed. The large-span base effectively disperses gravity and processing forces. The machine structure is sturdy, with high bed rigidity and processing stability.
3. System
Equipped with original Mitsubishi system, which is powerful and has excellent data processing capability. The original high-power Mitsubishi main motor provides excellent stability, fast response, and high accuracy.
4. Dual Tool Magazine
The machine comes with a dual tool magazine structure with the high-speed ATC system. Multiple processes done within only one setup such as milling, drilling, tapping of large and medium-batch parts, greatly improves production efficiency.
TH-600NCH | Value | Unit | |
Capacity | Max. workpiece length | 600(Rotary table) | mm |
Max. workpiece width | 600 | mm | |
Max. workpiece height | 550 | mm | |
Worktable | Size | 600×600 | mm |
Max. load | 2000 | kg | |
Spindle(Belt-driven) | Spindle | φ190 | / |
Spindle motor output | 2×18.5 | kW | |
Spindle taper | BT50 | / | |
Spindle RPM | 50-1500 | rpm | |
Drilling diameter (steel parts) | 10-20 | mm | |
Tapping (steel parts) | M12-M24 | / | |
Max. cutting amount | 2×1.5 | mm | |
Cutter diameter | 150 | mm | |
Max. tool length | 280 | mm | |
Servo motor | X/Y1/Y2/Z1/Z2/B axis output | 3/3/3/3/3/2 | kW |
X/Y/Z traverse rate | 8000 | mm/min | |
ATC | No. of tool of ATC | 24 | pcs |
Machine weight & size | Weight | 16 | T |
Size (L*W*H) | 5563×4325×3207 | mm |
*Note: Parameter above is for reference only, please contact us for more detailed data or inquire customized solutions.
